Transparent Window Display Screen
- Description
- Specification parameters
-
Simple and gorgeous
Hidden line connection, simple but not simple
• High Permeability • Quality guarantee
• Original design • Quick installation
Hd display silky smooth
High refresh rate: ≥1920
High light: ≥500cd/m²
As thin as a cicada's wings
Compared with the traditional screen weight reduction of more than 60% per square is only 8.5KG, the overall thickness of the product is only 35mm
Gorgeous and transparent
Transparent and gorgeous advertising perfect fit
-
Item
Specification
LED Lamp
SMD2121
LED Type
Surface Mounted 3-in-1
Pixel Pitch (mm)
Horizontal 3.9mm / Vertical 7.8mm
Module Resolution (W×H)
128 × 16
Module Size (mm) (W×H×D)
500 × 125 × 5
Cabinet Module Configuration
2 × 8
Cabinet Resolution (W×H)
256 × 128
Cabinet Size (mm) (W×H×D)
1000 × 1000 × 68
Cabinet Quantity (㎡)
1
Cabinet Weight (kg)
8 ± 0.5
Pixels per Square Meter
32768
Brightness (cd/m²)
≥500
Horizontal Viewing Angle
140° ± 10°
Vertical Viewing Angle
140° ± 10°
Transparency
≥60%
Brightness Uniformity
≥97%
Max Power Consumption (W/㎡)
340
Avg Power Consumption (W/㎡)
160
Power Input
AC 200–240V (47–63Hz)
Refresh Rate (Hz)
≥1920
Frame Rate (Hz)
60
Drive Mode
Constant Current, 1/16 scan
Lifespan (hrs)
100,000
Operating Temperature (℃)
-10 ~ +40
Storage Temperature (℃)
-20 ~ +60
Operating Humidity (RH)
10%–65%, non-condensing
Storage Humidity (RH)
10%–65%, non-condensing
